Product Range
Goosenecks
Fixed and Sliding Goosenecks
| SKU | Title | backing plate thickness mm | backing plate width mm | fixing hole diameter mm | groove width mm | pin diameter mm | to suit mast diameter mm | Length mm | Weight g | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
A.120 | Spare Gooseneck Nut | - | - | - | - | - | - | - | 5 | £5.38 |
 |
A1678 | Gooseneck Socket Body | - | 47 | 5 | - | 9 | - | - | 41 | £41.56 |
 |
A1679 | Fixed Pin Gooseneck Fitting | - | - | - | - | 9 | - | - | 88 | £53.29 |
 |
A1679-PIN | Gooseneck Pin With Nut | - | - | - | - | 9 | - | - | 45 | £25.55 |
 |
A1680 | Assembled Gooseneck | - | 72 | 5 | - | 9 | 60 - 90 | - | 134 | £58.84 |
 |
A1681 | Mast Gooseneck Fittings With Removable Pin | - | 72 | 5 | - | 6 | 60 - 90 | - | 70 | £32.8 |
 |
A1682 | Goosneck Pin With Pivot Bracket | - | - | - | - | 9 | - | - | 66 | £21.54 |
 |
A1685 | Loose Gooseneck Pin | - | - | - | - | 9 | - | - | 44 | £11.45 |
 |
A1686 | Mast Gooseneck Fitting With Pivot | - | 72 | 5 | - | 9 | 60 - 90 | - | 92 | £45.94 |
 |
A4009C | Stainless Steel Gooseneck With Radiused Strap | - | - | 4 | - | 13.6 | 50 - 55 | - | 78 | £35.09 |
 |
A4009K | Stainless Steel Gooseneck With V Strap | - | - | 4 | - | 13.6 | 50 | - | 78 | £35.09 |
|
A4009K-10 | Stainless Steel Gooseneck With V Strap | - | - | 4 | - | 10 | 50 | - | 78 | £37.24 |
|
A4009LZ | Stainless Steel Gooseneck With Radiused Strap | - | - | 4 | - | 13.6 | 55 | - | 78 | £35.09 |
|
A4009LZ-10 | Stainless Steel Gooseneck With Radiused Strap | - | - | 4 | - | 10 | 55 | - | 78 | £37.24 |
 |
A4114-1 | Aluminium Sliding Gooseneck | 10 | 11 | - | 7 | 13.6 | - | - | 101 | £42.59 |
|
A4114-2 | Aluminium Sliding Gooseneck | 4 | 16 | - | 9 | 13.6 | - | - | 94 | £53.16 |
|
A4114-3 | Aluminium Sliding Gooseneck | 6 | 16 | - | 8 | 13.6 | - | - | 104 | £42.59 |
 |
ASP4109 | Laser/ ILCA Gooseneck | 2 | 45 | 5 | - | 12 | - | - | - | £25.24 |
