Product Range
Batten Hardware
A range of nylon batten pockets to cover the end of battens.
| SKU | Title | To Suit Batten Width mm | To Suit Batten Thickness mm | Length Overall mm | Width Overall mm | Thickness Overall mm | To Suit Batten Diameter mm | Length mm | Weight g | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 | A..51 | Batten Pocket Protector With SS Screws | 27 | 5 | 46 | 20 | 10 | - | 46 | 7 | £1.72 |
 | A.151 | Batten Pocket Protector With Brass Screws | 34 | 4 | 47 | 10 | 9 | - | 47 | 3 | £2.08 |
 | A.351 | Batten Pocket Protector Brass Screws | 40 | 5 | 64 | 30 | 10 | - | 64 | 11 | £4.24 |
 | A.451 | Batten Pocket Protector With Brass Screws | 25 | 6 | 43 | 34 | 16 | - | 43 | 13 | £4.64 |
 | A.651 | Batten End Cap | 14.5 | 6 | 33 | 28 | 10 | - | 33 | 20 | £1.30 |
 | A.751 | Batten End Cap | 20 | 7 | 20 | 32 | 10 | - | 20 | 6 | £1.06 |
 | A.251 | Batten Pocket Protector With Brass Screws | 60 | 7 | 85 | 15 | 13 | - | 85 | 13 | £2.98 |
 | A.851 | Batten Pocket Protector With SS Screws | 23 | 5 | 64 | 35 | 10 | - | 64 | 15 | £5.26 |
 | A.101 | Batten Compression Adjuster | 14 | 9 | 71 | 28 | 20 | - | 71 | 8 | £3.31 |
 | A.419S | Batten Pocket Protector - Short | 42 | 6 | 70 | 63 | 25 | 15 | 70 | 80 | £27.97 |
 | A.102 | Stainless Steel Batten Pocket Connector | - | 10 | 66 | 18 | - | - | 66 | 47 | £29.08 |
 | A.419L | Batten Pocket Protector - Long | 53 | 10 | 91 | 78 | 32 | 22 | 91 | 142 | £27.97 |
 | A.951-10 | Inboard Batten Adjuster | 10 | 4 | 62 | 35 | 17 | - | £22.92 | ||
 | A.951-18 | Inboard Batten Adjuster | 19 | 6.5 | 64 | 42 | 20 | - | £26.95 | ||
 | A.952-8 | 8mm Inboard Clam Shell Batten End | 25 | 8 | 61.55 | 58 | 8 | 8 x 25 | 0 | £51.98 | |
 | A.952-11 | 11mm Inboard Clam Shell Batten End | 25 | 11 | 61.55 | 58 | 11 | 11 x 25 | 0 | £51.98 |
