Product Range
Round Body Shackles
Round body bow shackle with forged pin
Filters:
Body Type
- Bow
- D
- Long D
- Twisted
Pin Diameter mm
- 4
- 5
- 6
- 8
- 10
- Clear All
| SKU | Title | L mm | A mm | D mm | W mm | Breaking Load Kg | Length mm | Weight g | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 | A-621104 | D Shackle With 4mm Forged Pin | 16 | 9 | 4 | - | 500 | 16 | 6 | £2.39 |
 | A-621105 | D Shackle With 5mm Forged Pin | 18 | 11 | 5 | - | 950 | 20 | 13 | £2.60 |
 | A-621106 | D Shackle With 6mm Forged Pin | 22 | 13 | 6 | - | 1500 | 24 | 24 | £3.37 |
 | A-621108 | D Shackle With 8mm Forged Pin | 32 | 16 | 8 | - | 2500 | 32 | 55 | £5.38 |
 | A-621110 | D Shackle With 10mm Forged Pin | 40 | 20 | 10 | - | 4100 | 40 | 109 | £7.72 |
 | A-622104 | Bow Shackle With 4mm Forged Pin | 20 | 8 | 4 | 13 | 500 | 20 | 8 | £2.47 |
 | A-622105 | Bow Shackle With 5mm Forged Pin | 23 | 11 | 5 | 17 | 950 | 25 | 15 | £2.98 |
 | A-622108 | Bow Shackle With 8mm Forged Pin | 36 | 18 | 8 | 28 | 2500 | 41 | 59 | £5.74 |
 | A-622106 | Bow Shackle With 6mm Forged Pin | 27 | 14 | 6 | 21 | 1500 | 30 | 26 | £3.23 |
 | A-624105 | Twisted Shackle With 5mm Forged Pin | 33 | 11 | 5 | - | 950 | 24 | 16 | £3.80 |
 | A-624106 | Twisted Shackle With 6mm Forged Pin | 33 | 13 | 6 | - | 1500 | 30 | 28 | £4.61 |
 | A-624108 | Twisted Shackle With 8mm Forged Pin | 40 | 18 | 8 | - | 2500 | 36 | 65 | £7.37 |
 | A-624110 | Twisted Shackle With 10mm Forged Pin | 44 | 16 | 10 | - | 4100 | 44 | 0 | £10.66 |
 | A-623104 | Long D Shackle With 4mm Forged Pin | 32 | 8 | 4 | - | 500 | 32 | 9 | £2.56 |
 | A-623105 | Long D Shackle With 5mm Forged Pin | 40 | 10 | 5 | - | 950 | 40 | 20 | £3.31 |
 | A-623106 | Long D Shackle With 6mm Forged Pin | 48 | 12 | 6 | - | 1500 | 48 | 0 | £4.36 |
 | A-623108 | Long D Shackle With 8mm Forged Pin | 60 | 17 | 8 | - | 2500 | 64 | 73 | £7.69 |
 | A-623110 | Long D Shackle With 10mm Forged Pin | 80 | 20 | 10 | - | 3000 | 80 | 8 | £13.08 |
