Product Range
Goosenecks
Fixed and Sliding Goosenecks
| SKU | Title | pin diameter mm | fixing hole diameter mm | to suit mast diameter mm | groove width mm | backing plate width mm | backing plate thickness mm | Length mm | Weight g | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 | A4114-1 | Aluminium Sliding Gooseneck | 13.6 | - | - | 7 | 11 | 10 | 200 | 101 | £42.59 |
 | A4114-2 | Aluminium Sliding Gooseneck | 13.6 | - | - | 9 | 15.70 | 3.40 | 200 | 94 | £53.16 |
 | A4114-3 | Aluminium Sliding Gooseneck | 13.6 | - | - | 7.90 | 15.60 | 5.60 | 200 | 104 | £42.59 |
 | A..14R | Alloy Gooseneck With Round Pin | 12 | 5 | 40 | - | - | - | 90 | 66 | £44.16 |
 | A..14S | Alloy Gooseneck With Square Pin | 12 | 5 | 40 | - | - | - | 90 | 66 | £48.62 |
 | A4009K | Stainless Steel Gooseneck With V Strap | 13.6 | 4 | 50 | - | - | - | 200 | 78 | £35.09 |
 | A4009K-10 | Stainless Steel Gooseneck With V Strap | 10 | 4 | 50 | - | - | - | 200 | 78 | £37.24 |
 | A4009LZ | Stainless Steel Gooseneck With Radiused Strap | 13.6 | 4 | 55 | - | - | - | 200 | 78 | £35.09 |
 | A4009LZ-10 | Stainless Steel Gooseneck With Radiused Strap | 10 | 4 | 55 | - | - | - | 200 | 78 | £37.24 |
 | A4009C | Stainless Steel Gooseneck With Radiused Strap | 13.6 | 4 | 50 - 55 | - | - | - | 200 | 78 | £35.09 |
 | A.120 | Spare Gooseneck Nut | - | - | - | - | - | - | 200 | 5 | £5.38 |
 | ASP4109 | Laser/ ILCA Gooseneck | 12 | 5 | - | - | 45 | 2 | £25.24 | ||
 | A1678 | Gooseneck Socket Body | 9 | 5 | - | - | 47 | - | £41.56 | ||
 | A1679-PIN | Gooseneck Pin With Nut | 9 | - | - | - | - | - | £25.55 | ||
 | A1679 | Fixed Pin Gooseneck Fitting | 9 | - | - | - | - | - | £53.29 | ||
 | A1680 | Assembled Gooseneck | 9 | 5 | 60 - 90 | - | 72 | - | £58.84 | ||
 | A1682 | Goosneck Pin With Pivot Bracket | 9 | - | - | - | - | - | £21.54 | ||
 | A1685 | Loose Gooseneck Pin | 9 | - | - | - | - | - | £11.45 | ||
 | A1686 | Mast Gooseneck Fitting With Pivot | 9 | 5 | 60 - 90 | - | 72 | - | £45.94 | ||
 | A1681 | Mast Gooseneck Fittings With Removable Pin | 6 | 5 | 60 - 90 | - | 72 | - | £32.80 |
