Product Range
Wire Fork Terminals
316 Stainless steel fork terminal for wire rigging
| SKU | Title | internal body diameter mm | external body diameter mm | pin diameter mm | length from pin centre mm | body length mm | fork width mm | Length mm | Weight g | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 | A6166 | Stainless Steel Fork Terminal For 2.5mm Wire | 2.8 | 5.5 | 5 | 58 | 32 | 7 | 58 | 2 | £14.05 |
 | A6167 | Stainless Steel Fork Terminal For 3mm Wire | 3.5 | 6.35 | 5 | 65 | 38 | 7 | 65 | 2.3 | £12.34 |
 | A6168 | Stainless Steel Fork Terminal For 3mm Wire | 3.5 | 6.35 | 6 | 66 | 38 | 9 | 66 | 2.8 | £14.05 |
 | A6169 | Stainless Steel Fork Terminal For 4mm Wire | 4.4 | 7.5 | 5 | 71 | 45 | 7 | 71 | 2.7 | £11.77 |
 | A6170 | Stainless Steel Fork Terminal For 4mm Wire | 4.4 | 7.5 | 6 | 73 | 45 | 9 | 73 | 3.4 | £13.27 |
 | A6265 | Low Profile Fork | 2 | - | 5 | 49 | 32 | 2.8 | £22.12 | ||
 | A6266 | Low Profile Fork | 2.5 | 5.5 | 5 | 49 | 49 | 2.8 | £18.95 | ||
 | A6267 | Low Profile Fork | 3 | 6.35 | 5 | 60 | 38 | 5.2 | £26.96 | ||
 | A6268 | Low Profile Fork | 4 | 7.5 | 6.35 | 67 | 67 | 5.2 | £41.88 |
