Range / Blocks / 60mm dynamic blocks

Quint

A2069

£267.58

8 in stock (can be backordered)


By adding this item to my basket I agree I have read and understood the terms and conditions of sale.
Stockists
SKU: A2069 Category:

Description

60mm Quint Dynamic Block.



Designed for use as a low friction mainsheet system on sports catamarans, but suitable for many other applications including backstay tensioning on keelboats.



For a complete 10:1 mainsheet system, also look at A2169 – Pro-Ratchet 60mm Quint Block.



Bearings – Dynamic Blocks feature our patented bearing system which uses twin rows of stainless-steel ball bearings running on a stainless-steel rail. This provides a superior load-carrying ability and longevity when compared to other bearing systems available on the market.



Swivel Lock – The A2069 comes with a removable swivel lock moulding. When installed, the shackle can be locked in 90-degree orientations. When removed, the attachment shackle can spin freely.



Becket – A large central hole not only reduces the overall weight of the block but also offers a rope friendly attachment point.

Reviews

There are no reviews yet.

Be the first to review “Quint”

This site uses Akismet to reduce spam. Learn how your comment data is processed.

Quint

SKU Title Maximum Line Diameter mmshackle pin mmbreaking load kgmaximum working load kgfixing hole centres mm Length mm Weight g Price
A2060 Single 1051000500- 118 126 £267.58
A2062 Double 1051250600- 130 255 £267.58
A2064 Triple 1051250600- 130 353 £267.58
A2066 Quad 1251250600- 130 443 £267.58
A2063 Double With Becket 1051250600- 148 271 £267.58
A2065 Triple With Becket 1051250600- 148 397 £267.58
A2067 Quad With Becket 1051250600- 148 456 £267.58
A2069 Quint 1051250600- 130 549 £267.58
A2060C Single Cheek Block 105100050060 115 149 £267.58
A2069B Quint With Becket 1061250600- 150 £267.58
A2060TII- Single Tii-On 10-1400700- 84 91 £267.58
A2166 Cheek Adaptor For 60mm Block ----60 £267.58
